A Concise Guide to Ceramic Capacitors and Their Dielectrics
This PDF download covers the basic aspects of ceramic capacitors - everything you need to know to understand them, their diectrics and the codes associated with them.
The download provides a concise introduction and summary of these important capacitors which are used in almost every electronic circuit. The download is an ideal companion for anyone starting in electronics, or anyone wanting a refresher.
The download is just under 3000 words long and it extends to around 12 content pages, so there is plenty of information contained within it for both the newcomer and more seasoned hand.
Contents:
Understanding Ceramic Capacitors: types
Ceramic capacitor basics
Ceramic dielectric types
Ceramic capacitor dielectric classes
Class 1 ceramic capacitor dielectric
Class 1 capacitor codes:
Class 2 ceramic capacitor dielectric 1
Class 2 capacitor codes
Capacitor marking codes: the basics
Download it now because it is packed full of the information you need.
